Hisun HS200UTV - Panel and Cargo Bed

-169-
CHASSIS
- 169-
PANEL AND CARGO BED
Front Panel
No. Part Name Qty Remarks
Removing the front panel
1
Front cover 1
2
Socket hexagon flat head screws M6×16 12
3
Clip for bolt
M6×2 8
4
Front left mudguard 1
5
Socket hexagon flat head screws M6×16 16
6
Front right mudguard 1
7
Front panel 1
8
Knobs 2
9 H-shaped rubber ring 2
