Hisun HS200UTV - Side Cover

-171-
CHASSIS
- 171-
Side Cover
No. Part Name Qty Remarks
Removing the side cover
1
Left Board 1
2
Right Board 1
3
Socket Hexagon Flat Head Screws M6×16 14
4
Clip For Bolt M6×2 14
5
Left Door Comp. 1
6
Right Door Comp. 1
7
Bolt M6×16 8
8
Gemel Pin Φ10×Φ17×44 4
9
Split Washer Φ8×1 4
10
Cross Small Plate Head Screw M5×16 8
11
Door lock pin 2
12
door lock bracket II（L）
1
13
door lock bracket I（L）
1
14
door lock assy 2
15
Hexagon Flange Bolt M6×16 4
16
door lock bracket I（R）
1
17
door lock bracket II（R）
1
18 Hexagon Flange Bolt M5 8
