Hisun HS200UTV - Side Cover Parts

-172-
CHASSIS
- 172-
Side Cover Parts
No. Part Name Qty Remarks
Removing the side cover parts
1 Inner wind board 1
2 Socket hexagon flat head screws M6×16 8
3 Clip for bolt M6 × 2 9
4 Brake pedal assy. 1
5 Hexagon flange bolt M10×1.25×60 1
6 Brake pedal bushing II 1
7 Return spring , rear brake Φ1.2×Φ7×38 1
8 Hexagon flange locked Nut M10×1.25 1
9 Accelerator pedal welding assy. 1
10 Cotter pin 2×32 1
CHASSIS
- 173-
No. Part Name Qty Remarks
11 Mounting seat assy., accelerator pedal 1
12 Hexagon socket head bolt M6×20 4
13 Washer Φ8×Φ16×1.6 1
14 Torsional spring I 1
15 Throttle cable 1
16 Engine cover board 1
17 Knobs 4
18 H-shaped rubber ring 4
19 Battery cover 1
20 Knobs 1
21 H-shaped rubber ring 1
22 Seat mounting board 1
