Hisun HS200UTV - Page 188

-173-
CHASSIS
- 173-
No. Part Name Qty Remarks
11 Mounting seat assy., accelerator pedal 1
12 Hexagon socket head bolt M6×20 4
13 Washer Φ8×Φ16×1.6 1
14 Torsional spring I 1
15 Throttle cable 1
16 Engine cover board 1
17 Knobs 4
18 H-shaped rubber ring 4
19 Battery cover 1
20 Knobs 1
21 H-shaped rubber ring 1
22 Seat mounting board 1
