Front Suspension
No. Part Name Qty Remarks
Removing the front suspension
1
Front left upper swing arm
1
2
Front right upper swing arm
1
3
Front left lower swing arm
1
4
Front right lower swing arm
1
5
Front swing arm bushing
8
6
Middle rubber tube, swing arm
16
7
Hexagon flange bolt M10×1.25×70
8
8
Hexagon flange locked nut M10×1.25
8
CHASSIS
- 215-
No. Part Name Qty Remarks
9
Suspension of universal joint A
4
10
Elasticity block ring d=30
4
11
Front left steering knuckle assy.
1
12
Front right steering knuckle assy.
1
13
Socket hexagon screw M10×1.25×20
4
