ENGINE REMOVAL
No. Part Name Qty Remarks
Removing throttle and intake
manifold.
Remove the parts in the order listed.
1 Cylinder screw M6×20 Inner 2
2 Fuel injector fixed seat 1
3 Injector 1
4 Cylinder screw M6×25 Inner 2
5 Intake-tube 1
6 Joint inlet pipe 1
7 Inlet pipe hoop 2
8 Throttle（D34） 1
For installation, reverse the removal
procedure.
