Hisun HS200UTV - Wheel and Tyre Parts

-202-
CHASSIS
- 202-
WHEEL AND TYRE PARTS
FRONT WHEELS
No. Part Name
Qty Remarks
Removing the front wheel
1 Front tyre 2
2 Front wheel rim 2
3 Front hub 2
4 Bearing 6004-RZ 2
5 Front steering knuckle oil seal 2
6 Inner bushing I 2
7 Bearing 6202-RS 2
WARNING:
Securely support the vehicle so
There is no danger of it falling over.
8 Oil Seal, front knuckle Φ23×Φ35×7 2
9 Front brake pad 2
10 Hexagon step bolt M8×15-Φ15×5 8
CHASSIS
- 203-
No. Part Name
Qty Remarks
11 Bolt 8
12 Nut 2
13 Wheel decoration cover 2
WARNING:
Securely support the vehicle so
There is no danger of it falling over.
14 Nut M10 8
