SPECIFICATIONS
- 74-
Chassis tightening torques
Part to be tightened
Thread
size
Tightening torque
Remarks
Nm m · kg ft · lb
Engine and Rubber connecting bracket 2 (front) M10 52 5.2 37
M6 10 1.0 7.2
Engine and Rubber connecting bracket 1 (rear) M8 33 3.3 24
M6 10 1.0 7.2
Rear knuckle and rear lower arm M10 45 4.5 32
Rear shock absorber and frame M10 45 4.5 32
Rear shock absorber and rear lower arm M10 45 4.5 32
Universal joint yoke and drive pinion gear M14 62 6.2 45
Ring gear bearing housing and final drive gear case M8 23 2.3 17
M10 40 4.0 29
Ring gear stopper nut M8 16 1.6 11
Bearing retainer and final gear pinion gear bearing housing
M65 170 17.0 125
Left-hand
threads
Coupling gear and final drive pinion gear M12 80 8.0 58
Front upper arm and frame M10 45 4.5 32
Front lower arm and frame M10 45 4.5 32
Front shock absorber and frame M10 45 4.5 32
Front shock absorber and front upper arm M10 45 4.5 32
Steering shaft assembly and steering Cross gimbal M8 22 2.2 16
Steering assembly and steering Cross gimbal M8 22 2.2 16
Steering assembly and frame M10 48 4.8 35
Steering shaft assembly and frame M8 21 2.1 15
Steering wheel and steering shaft assembly M12 35 3.5 25
Steering knuckle and front upper arm M12 30 3.0 22
Steering knuckle and front lower arm M12 30 3.0 22
Tie-rod locknut M12 40 4.0 29
Steering knuckle and tie-rod M12 39 3.9 28
Front lower arm protector board and front lower arm M6 7 0.7 5.1
Seat belt and frame M10 59 5.9 43
Seat belt and ceiling (enclosure) 7/16 59 5.9 43
Front wheel and front wheel hub M10 55 5.5 40
Front wheel hub and constant velocity joint of half
shaft
M20 260 26.0 190 Stake
Steering knuckle and brake disc guard M6 7 0.7 5.1
Front brake caliper and front wheel steering knuckle M10 48 4.8 35
Front brake hose union bolt M10 27 2.7 19
Front brake hose holder and steering knuckle M6 7 0.7 5.1
Front brake hose holder and front upper arm M6 7 0.7 5.1
Front brake hose holder and frame M6 7 0.7 5.1
Front brake pad holding bolt M8 18 1.8 13
Front brake disc and front wheel hub M8 30 3.0 22
Front brake caliper bleed screw M6 6 0.6 4.3
SPECIFICATIONS
- 75-
Part to be tightened
Thread
size
Tightening torque
Remarks
Nm m · kg ft · lb
Rear wheel and rear wheel hub M10 55 5.5 40
Rear wheel hub and constant velocity joint of half shaft
M20 260 26.0 190 Stake
Rear brake hose and frame M6 7 0.7 5.1
Brake pipe and brake master cylinder
M10 19 1.9 13
Pedal holder assembly and frame M8 16 1.6 11
Brake master cylinder and pedal holder assembly M8 16 1.6 11
Secondary brake master cylinder kit stopper bolt M6 9 0.9 6.5
Brake rod locknut M8 17 1.7 12
Rear brake disc and brake disc Install seat M6 10 1.0 7.2
Rear brake pad holding bolt M8 17 1.7 12
Rear brake caliper and Install seat M10 40 4.0 29
Rear brake hose union bolt M10 27 2.7 19
Parking brake case and rear brake caliper M8 22 2.2 16
Parking brake lever assembly and frame M6 7 0.7 5.1
Rear brake caliper bleed screw M6 5 0.5 3.6
Upper instrument panel and frame M6 7 0.7 5.1
Support frame (enclosure) and frame M10 64 6.4 46
Support frame (enclosure) and side frame
(enclosure)
M10 64 6.4 46
Top frame (enclosure) and side frame (enclosure) M10 64 6.4 46
Seat support and frame M8 16 1.6 11
Footrest plate and frame M6 7 0.7 5.1
