Hisun HS200UTV - Cooling System

-225-
CHASSIS
- 225-
COOLING SYSTEM
Water Radiator
No. Part Name Qty Remarks
Removing the radiator
1
Water tank 1
2
Rubber cushion,water tank 2
3
Hexagon flange self-locked bolt M6×20 2
4
Water inlet assy 1
5
Hexagon flange bolt M6×16 2
6
Water pipe E 1
7
Screw clip Φ20×32 12
8
Front left water pipe 1
9
Front right water pipe 1
10
Rear left water pipe 1
11
Rear right water pipe 1
