Rear Swing Arm Assy.
No. Part Name Qty Remarks
Removing the rear swing arm assy.
1
Rear suspension assy 1
2
Rear suspension bushing 2
3
Hexagon flange bolt M12×1.25×75 2
4
Hexagon flange self-lock nuts M12×1.25 2
5
Rear shock absorber 2
6
Hexagon flange bolt M10×1.25×60 4
7
Hexagon flange self-lock nuts M10×1.25 4
8
Sprocket cover bracket welded assy 1
9
Hexagon flange bolt M8×1.25×20 3
10
Chain protecing bush Ⅰ 3
