Hisun HS200UTV - Chassis Specifications

-67-
SPECIFICATIONS
- 67-
CHASSIS SPECIFICATIONS
Item Standard Limit
Steering system
Type Fan gear and gear ----
Front suspension
Shock absorber travel
Spring free length
Spring fitting length
Spring rate
Stroke
91 mm (3.58 in)
260 mm (10.24 in)
243 mm (9.57in)
13 N/mm(1.33kg/mm, 72.79lb/in)
23-92 mm (0.91 ~ 3.62in)
----
----
----
----
Rear suspension
Shock absorber travel
Spring free length
Spring fitting length
Spring rate
Stroke
110 mm (4.33 in)
255 mm (10.04 in)
250 mm (9.84 in)
11.2 N/mm (1.14 kg/mm, 62.71lb/in)
18.4N/mm (1.88kg/mm, 103.02 lb/in)
0 ~ 63 mm (0 ~ 2.48 in)
63 ~ 106 mm (2.48 ~ 4.17in)
----
----
----
----
----
----
----
Front wheel
Type
Rim size
Rim material
Rim runout limit radial
lateral
Aluminum Alloy wheel
10 ×5.0 AT
ST12/ZL101A
----
----
----
----
----
1.0 mm
(0.04in)
1.0 mm
(0.04 in)
Rear wheel
Type
Rim size
Rim material
Rim runout limit radial
lateral
Aluminum Alloy wheel
10×8.0 AT
ST12/ZL101A
----
----
----
----
----
2.0 mm
(0.08 in)
2.0 mm
(0.08 in)
Brake lever and brake pedal
Accelerator pedal free play
Brake pedal free play
Parking brake cable free play
3 ~ 4mm (0.118 ~ 0.157 in)
2 ~ 3mm (0.079 ~ 0.118 in)
2 ~ 3 mm (0.079 ~ 0.118 in)
----
----
----
