Hisun HS200UTV - Shift and Control Mechanism

-161-
ENGINE
- 161 -
SHIFT AND CONTROL MECHANISM
No. Part Name Qty Remarks
Removing the shifting fork and Variable
speed drum
Remove the parts in the order liste
Gear case separation
1
Cir clip Φ12
5
2
Shifting fork
2
3
HR gear dpring
2
4
Shifting yoke Ⅱ
1
5
L gear spring
1
6
Flange bolt M6×25
1
7
Gate shift
1
8
Needle bearing
1
9
Variable speed drum
1
10
Oil seal 14×22×5
1
