-162-
ENGINE
- 162 -
No. Part Name Qty Remarks
11
Flange bolt M6×20
1
12
Shift reset board
1
13
Reset spring
1
14
Shifting forkⅡ
1
15
Shifting yoke I
1
For assembly, reverse the disassembly
procedure.
ENGINE
- 163 -
GEARCASE TRANSMISSION
No. Part Name Qty Remarks
Removing the gear case transmission Remove the parts in the order listed.
Gear case separation
1
Bearing 6204
3
2
Main shaft
1
3
Bearing 6202
1
4
Bearing 6202Z
2
5
Output shaft
1
6
Oil seal 20×34×7
1
7
Drive sprocket
1
8
Nut 14×1
1
9
Auxiliary shaft
1
For assembly, reverse the disassembly
procedure.
