-105-
MAINTENCE AND ADJUSTMENT OF THE UTV
- 105 -
ADJUSTING THE SELECT LEVER SHIFT ROD
① Neutral
② High
③ Low
④ Reverse
⑤ Select lever shift rod
WARNING
:
Before shifting, you must stop the vehicle and
take your foot off the accelerator pedal.
Otherwise, the transmission may be damaged.
1. Adjust:
·Select lever shift rod
a. Make sure the select lever is in NEUTRAL.
b. Loosen both locknuts ⑥.
WARNING
:
The select lever shift rod locknut (select lever
side) has left-handed threads. To loosen the
locknut, turn it clockwise.
c. Tighten the locknuts ⑥.
.
To Next Page
