-235-

ELECTRICAL COMPONENTS

- 235 -

ELECTRICAL

ELECTRICALCOMPONENTS

1. Thermo switch 1

2. Thermo switch2

3. Ignition coil

4. Speed sensor

5. stator assembly

6. Gear position switch

7. Fuel pump

8. Brake light switch

9. Radiator fan
