FUEL TANK
No. Part Name Qty Remarks
Removing the fuel tank
1 Fuel tank 1
2 Fuel pump 1
3 Cover, fuel pump(EFI engine) 1
4 Fuel Tank cap 1
5 Rubber cusion VIII 4
6 Hexagon flange self-locked bolt M6×20 2
7 Fuel pipe L=250 Φ14×Φ17×250 1
8 Collar bushing Φ7×Φ9.5×Φ20×7 3
9 Plug for fuel outlet(EFI Engine) 1
10 Clamp 2
