Hisun HS200UTV - Suspension

-212-
CHASSIS
- 212-
SUSPENSION
Front Swing Arm
No. Part Name Qty Remarks
Removing the front swing arm
1
Balance lever 1
2
Tie rod assy., balance lever 2
3
Hexagon flange bolt M8×1.25×35 2
4
Hexagon flange bolt M8×1.25×30 2
5
Hexagon flange nut M8×1.25 4
6
Press board, anti-roller lever 2
7
Hexagon flange bolt M8×1.25×20 4
8
U-shaped rubber sleeve 2
CHASSIS
- 213-
No. Part Name Qty Remarks
9
Front shock absorber 2
10
Bolt M10×1.25×50 4
11
Hexagon flange locked nut M10×1.25 4
