-66-
SPECIFICATIONS
- 66-
Item Standard Limit
Shifter
Shifter type Shift drum and guide bar ----
Air filter oil grade Engine oil ----
Oil pump
Oil filter type
Oil pump type
Tip clearance
Side clearance
Body clearance
Oil pressure (hot)
Pressure check location
Chartaceous
Inner and outer rotator
0.15 mm
(0.0059 in)
0.03 ~ 0.10 mm
(0.0012 ~ 0.0039 in)
0.09 ~ 0.17 mm
(0.0035 ~ 0.0067 in)
100 Kpa (1.02 kg/cm2, 14.5 psi)
at 1,500 r/min
Cylinder head
----
---
----
----
----
----
----
----
----
----
----
----
Water pump
Type
Reduction ratio
Single-suction centrifugal pump
22/18 (1.2)
----
----
Cooling system
Radiator core
Width
Height
Thickness
Radiator cap opening pressure
Radiator capacity
(including all routes)
Coolant reservoir
Capacity
From low to full level
355mm (13.98 in)
195mm (7.68 in)
38 mm (1.50 in)
107.9 ~ 137.3 Kpa
(1.079~1.373 kg /cm2, 15.35~19.53 psi)
0.6 L (0.5 Imp qt, 0.63 US qt
0.63 L (0.56 Imp qt, 0.67 US qt)
0.20 L (0.18 Imp qt, 0.21 US qt)
----
----
----
----
----
----
----
SPECIFICATIONS
- 67-
CHASSIS SPECIFICATIONS
Item Standard Limit
Steering system
Type Fan gear and gear ----
Front suspension
Shock absorber travel
Spring free length
Spring fitting length
Spring rate
Stroke
91 mm (3.58 in)
260 mm (10.24 in)
243 mm (9.57in)
13 N/mm(1.33kg/mm, 72.79lb/in)
23-92 mm (0.91 ~ 3.62in)
----
----
----
----
Rear suspension
Shock absorber travel
Spring free length
Spring fitting length
Spring rate
Stroke
110 mm (4.33 in)
255 mm (10.04 in)
250 mm (9.84 in)
11.2 N/mm (1.14 kg/mm, 62.71lb/in)
18.4N/mm (1.88kg/mm, 103.02 lb/in)
0 ~ 63 mm (0 ~ 2.48 in)
63 ~ 106 mm (2.48 ~ 4.17in)
----
----
----
----
----
----
----
Front wheel
Type
Rim size
Rim material
Rim runout limit radial
lateral
Aluminum Alloy wheel
10 ×5.0 AT
ST12/ZL101A
----
----
----
----
----
1.0 mm
(0.04in)
1.0 mm
(0.04 in)
Rear wheel
Type
Rim size
Rim material
Rim runout limit radial
lateral
Aluminum Alloy wheel
10×8.0 AT
ST12/ZL101A
----
----
----
----
----
2.0 mm
(0.08 in)
2.0 mm
(0.08 in)
Brake lever and brake pedal
Accelerator pedal free play
Brake pedal free play
Parking brake cable free play
3 ~ 4mm (0.118 ~ 0.157 in)
2 ~ 3mm (0.079 ~ 0.118 in)
2 ~ 3 mm (0.079 ~ 0.118 in)
----
----
----
