Front disc brake
Type
Disc outside diameter × thickness
Pad thickness inner
Pad thickness outer
Master cylinder inside diameter
Caliper cylinder inside diameter
Brake fluid type
Dual
160 × 3 mm (6.30 × 0.12 in)
8.0 mm (0.31 in)
8.0 mm (0.31 in)
19.0mm (0.75in)
25.0mm （0.98in）
DOT 4
----
----
----
----
----
----
----
Rear disc brake
Type
Disc outside diameter × thickness
Pad thickness inner
Pad thickness
outer
Master cylinder inside diameter
Caliper cylinder inside diameter
Brake fluid type
Single
200× 3.5 mm (7.87× 0.14in)
8.0 mm (0.31 in)
8.0 mm (0.31 in)
19.0mm (0.75in)
25.0mm （0.98in）
DOT 4
----
----
----
----
----
----
----
SPECIFICATIONS
- 69-
ELECTRICAL SPECIFICATIONS
Item Standard Limit
Voltage 12 V ----
Ignition system
Ignition timing (BTDC)
Advancer type
8°±1°before TDC
ECU Digital type
----
----
Ignition coil
Minimum spark gap
Primary winding resistance
Secondary winding resistance
6 mm (0.24 in)
0.18 ~ 0.28 Ω at 20 °C (68 °F)
6.32 ~ 9.48 kΩ at 20 °C (68 °F)
----
----
----
Spark plug cap
Resistance
4.5~5.0 kΩ
----
High voltage cap
Resistance
4.5~5.0 kΩ
----
Oxygen sensor
type
25322728
----
Charging system
Nominal output
Charging coil resistance/color
14 V 23 A at 4,500 r/min
0.32 ~ 0.43Ωat 20 ℃ (68 °F)/White – White –
White
----
----
Rectifier/regulator
Regulator type
No load regulated voltage (DC)
Capacity
Withstand voltage
Semi conductor-Switch type
14.1 ~ 14.95 V
18 A
200 V
----
----
----
----
Battery
Specific gravity
1.32
----
Circuit breaker
Type
Speedmeter/ECU normal open fuse
Lighting system fuse
Ignition fuse
Auxiliary DC jack fuse
Relay coil fuse
Signaling system fuse
Backup fuse(odometer)
Fuse
5 A×1
15 A×1
15 A×1
10 A×1
10A×1
10 A×1
5 A×1
10 A×1
15 A×1
----
----
----
----
----
----
----
