Part to be tightened
Thread
size
Tightening torque
Remarks
Nm m · kg ft · lb
Rear wheel and rear wheel hub M10 55 5.5 40
Rear wheel hub and constant velocity joint of half shaft M20 260 26.0 190 Stake
Rear brake hose and frame M6 7 0.7 5.1
Brake pipe and brake master cylinder M10 19 1.9 13
Pedal holder assembly and frame M8 16 1.6 11
Brake master cylinder and pedal holder assembly M8 16 1.6 11
Secondary brake master cylinder kit stopper bolt M6 9 0.9 6.5
Brake rod locknut M8 17 1.7 12
Rear brake disc and brake disc Install seat M6 10 1.0 7.2
Rear brake pad holding bolt M8 17 1.7 12
Rear brake caliper and Install seat M10 40 4.0 29
Rear brake hose union bolt M10 27 2.7 19
Parking brake case and rear brake caliper M8 22 2.2 16
Parking brake lever assembly and frame M6 7 0.7 5.1
Rear brake caliper bleed screw M6 5 0.5 3.6
Upper instrument panel and frame M6 7 0.7 5.1
Support frame (enclosure) and frame M10 64 6.4 46
Support frame (enclosure) and side frame
(enclosure)
M10 64 6.4 46
Top frame (enclosure) and side frame (enclosure) M10 64 6.4 46
Seat support and frame M8 16 1.6 11
Footrest plate and frame M6 7 0.7 5.1
