Part to be tightened Part name
Thread
size
Q’ty
Tightening torque
Remarks
Nm m.kg ft · lb
Coolant reservoir Bolt M6 2 7 0.7 5.1
Radiator bracket and frame Bolt M6 4 7 0.7 5.1
Fuel pump Bolt M6 2 7 0.7 5.1
Fuel tank Bolt M8 2 30 3.0 22
Muffler stay Bolt M6 2 11 1.1 8.0
Muffler and exhaust pipe Bolt M8 1 20 2.0 14
Muffler bracket and muffler Bolt M8 2 20 2.0 14
Muffler bracket and frame Bolt M8 2 20 2.0 14
Muffler damper and muffler Bolt M6 1 10 1.0 7.2
Muffler damper and frame Bolt M6 1 10 1.0 7.2
Exhaust pipe Nut M8 2 14 1.4 10
Air duct assembly 1 Bolt M6 2 7 0.7 5.1
Air duct assembly 2 and left protector Bolt M6 1 7 0.7 5.1
Air duct assembly 2 and frame Bolt M6 1 7 0.7 5.1
Gear position switch Bolt M5 2 7 0.7 5.1
Thermo switch 1 (cylinder head)
— 1/8 1 8 0.8 5.8
Thermo switch 3 (radiator) — M18 1 28 2.8 20
Reverse switch — M10 1 20 2.0 14
Engine ground lead Bolt M6 1 10 1.0 7.2
Starter motor and engine Bolt M6 2 10 1.0 7.2
.
