-203-

CHASSIS

- 203-

No. Part Name

Qty Remarks

11 Bolt 8

12 Nut 2

13 Wheel decoration cover 2

WARNING:

Securely support the vehicle so

There is no danger of it falling over.

14 Nut M10 8
