-96-
MAINTENCE AND ADJUSTMENT OF THE UTV
.
12. Remove:
·air bleed bolt ①
13. Fill cooling
(with the specified amount of the recommended
coolant)
NOTE:
The specified amount of coolant is a standard
amount. Fill the cooling system with coolant
until coolant comes out of the hole for the air
bleed bolt.
Coolant is potentially harmful and should be
handled with special care.
WARNING
:
·
If coolant splashes in your eyes, thoroughly
wash them with water and consult a doctor
；
·
If coolant splashes on your clothes, quickly
wash it away with water and then with soap
and water
；
·
If coolant is swallowed, induce vomiting and
get immediate medical attention
；
·
If coolant comes into contact with painted
surfaces, immediately wash them with water
；
·
Do not mix different types of antifreeze.
Recommended antifreeze
High-quality ethylene glycol antifreeze
containing corrosion inhibitors for
aluminum engines
Mixing ratio
1 : 1 (antifreeze : water)
Quantity total amount
1.32 L
Coolant reservoir capacity
MAINTENCE AND ADJUSTMENT OF THE UTV
- 97 -
.
NOTE:
Adding water instead of coolant lowers the
antifreeze content of the coolant. If water is
used instead of coolant, check, and if
necessary, correct the antifreeze concentration
of the coolant. Use only distilled water.
However, soft water may be used if distilled
water is not available.
14. Install:
·
air bleed bolt
9 Nm (0.9 m · kg, 6.5 ft · lb)
·
radiator cap；
·Fill coolant reservoir；
·Install coolant reservoir cap:
·Start the engine, warm it up for several minutes,
and then turn it off.
·Check:
coolant level
Refer to “THE COOLANT” in chapter 4.
NOTE:
Before checking the coolant level, wait a few
minutes until the coolant has settled.
·Close the hood.
·Install driver seat
Refer to “SEATS,” in chapter 5.
CHECKING THE COOLANT TEMPERATURE
WARNING LIGHT
Coolant temperature indicator light ①
