-127-
ENGINE
- 127 -
No. Part Name Qty Remarks
14
Left cylinder head cover
1
15
Flange bolt M6×20
2
16
Washer Φ8×Φ15×2
1
17
Stud bolt M8×45
2
18
Flange bolt M6×110
2
19
Copper washer Φ10.5×Φ18×2
4
20
Cap nut M10
4
21
O-Ring Φ78×3
1
22
Hexagon socket screw M4×12
4
23
Cylinder head cover assembly
1
For installation, reverse the removal
procedure.
