Hisun HS200UTV - Page 170

-155-
ENGINE
- 155 -
No. Part Name Qty Remarks
12
Oil drain screw
1
13
O-ring 36×3.5
1
14
Mesh spring
1
15
Oil strainer
1
16
Water pipe connector Φ18
1
17
Locating pin 8×12
2
18
O-ring 9×2
2
19
Oil pump comp
1
20
Cross recessed countersunk head screw M6×30
2
21
Bolt M14×1.5×16
1
22
Aluminum gasket 14×22×1
1
For assembly, reverse the disassembly
procedure.
