Hitachi Compute Blade 500 Series Management Module Setup Guide

Item
Configuring from
the management
module console
Linking to the target
module
Remarks
1. The switch module console can be logged in without inputting the switch module
account.
2. Connect the OS console during LPAR manager is booting, you can connect the LPAR
manager console. For details about LPAR manager console, see the Hitachi Compute
Blade 500 Series Logical partitioning manager user's guide.
Tip: You need to set the role configuration in the account correctly for the
setting of each module. For details, see the Hitachi Compute Blade 500 Series
Web console user's guide and the Hitachi Compute Blade 500 Series CLI
console user's guide.
Table 2-65 Web console operation
Item Operation
Server blade (BMC)
configuration
Resources tab > Modules > All Modules > Server Blade >
Server Blade x > BMC
tab
Server blade (UEFI)
configuration
Resources tab > Modules > All Modules > Server Blade >
Server Blade x > EFI tab
LPAR manager
configuration
Resources tab > Modules > All Modules > Server Blade >
Server Blade x > LPAR tab
Hitachi LAN switch
module configuration
Resources tab > Modules > All modules > Switch Module >
Switch Module x > Configuration tab
Brocade 8 Gb/sec
Fibre Channel switch
module or Brocade
16 Gb/sec Fibre
Channel switch
module link to Web
console
Resources tab > Modules > All Modules > Switch Module >
Switch Module x > Configuration tab
Hitachi Fibre Channel
mezzanine card
configuration
Resources tab > Modules > All Modules > Server Blade >
Server Blade x > I/O card tab
Table 2-66 CLI console command
Item Command
Linking to CLI console of switch module
change console -s
Server blade (BMC settings)
The BMC settings can be configured by the management module. The setting
item is reflected immediately. For details about setting items, see the Hitachi
Compute Blade 500 Series Web Console User's Guide and Hitachi Compute
Blade 500 Series CLI Console User's Guide.
2-52
Functional detail
Hitachi Compute Blade 500 Series Management Module Setup Guide
