Each module configuration
This section describes configuration of each module in the system unit.
Configurable modules from management module
The management module, the server blade, the switch module, and others
are installed in the system unit. You need to set these modules configuration
for system construction and operation. You can set these modules
configuration by the management module console in the system unit. You can
also link to these module consoles by the management module console.
Therefore, you can set each module configuration seamlessly without
connecting each console when connecting the management module console.
The following table describes the configurable module items from the
management module console.
Table 2-63 Configurable module items from Web console
Item
Configuring from
the management
module console
Linking to
the target
module
Remarks
Server blade (BMC)
configuration
Y - -
Server blade (UEFI)
configuration
Y (partly) - -
LPAR manager configuration Y (partly) - For details, see
LPAR manager
cooperation
function on page
2-110.
Hitachi 1 Gb/sec LAN switch
module (20-port)
configuration
Y (partly) - -
Hitachi 1 Gb/sec LAN switch
module (40-port)
configuration
Y (partly) - -
Hitachi 1/10 Gb/sec LAN
switch module configuration
Y (partly) - -
Brocade 10 Gb/sec LAN
switch module configuration
- - -
Brocade 8 Gb/sec Fibre
Channel switch module
configuration
- Y -
Brocade 16 Gb/sec Fibre
Channel switch module
configuration
-
Y
1
-
Hitachi Fibre Channel
mezzanine card
configuration
Y - -
