１.３.２ Installation procedure
Perform an installation work of the unit according to the following procedure
at the unpacking.

Step Work Related page
1
Selection of ink used
(touch panel operation)
2.2 System environment
setup
2 Makeup ink replenishment
Instruction manual
6.4 Makeup ink
replenishment
3
Beam alignment
(air bleed and stream alignment of
makeup ink path)
Instruction manual
6.7 Adjusting the Ink
stream position
4
Ink replenishment (first replenishment)
(Replace a solvent with ink)
Instruction manual
6.5 Ink replacement
5
Ink drainage
(Drainage ink due to insufficient
replacement of a solvent with ink)
Instruction manual
6.5 Ink replacement
6
Ink replenishment
(second replenishment)
(Fill ink into a circulating system)
Instruction manual
6.5 Ink replacement
7
Viscometer calibration
(Touch panel operation, automatic
acquisition)
2.6
Viscometer calibration
8
Pressure adjustment
(Set pressure to the standard value of
every ink)
Instruction manual
6.12 Pressure adjustment
9
Adjustment of excitation voltage
(Touch panel operation, automatic
acquisition)
2.3.1
Excitation adjustment
10
Adjustment of APH gain
(Touch panel operation, automatic
acquisition)
2.3.4
Auto phase gain
adjustment
11
Setting of excitation voltage
(Confirm the real printing state and the
particle mode and then, set the
excitation voltage)
Instruction manual
6.13 Excitation setting
adjustment
12 Editing Print Data, etc.
−
 Serviceman password is “HALB”.
