Hitachi PB - Auto Phase Gain Adjustment

2-10
2.3.4 Auto phase gain adjustment
●The gain of the auto phase detection voltage is automatically adjusted.
●Perform this adjustment after confirmation that the periphery of a gutter part within
the nozzle head is not made dirty with ink or the like and the printing head cover is
correctly fixed.
●This adjustment is performed when the IJ printer is in a “warming up” or “standby” state.
●Be sure to perform this adjustment in the case of replacing the substrate (EZJ93, 94/106),
the CF card or the nozzle (including the print head) or changing the ink type.
In addition, perform this adjustment after carrying out “2.3.1 Excitation adjustment.”
１Press Adjustment/operational checkout at the second page of the
service maintenance screen.
When the Next menu are not displayed in the maintenance work menu, set to
the service personnel maintenance mode by the password protection.
 ２ Press Auto-phase gain adjustment. When the screen is switched,
press Automatic acquisition.
The gain of the auto phase detection voltage is automatically adjusted within the
IJ printer. During the automatic adjustment, a processing state is displayed to be
“Acquisition”.
With respect to the
Password protection,
refer to " 2.1 setting of
service personnel
maintenance mode"

Back
Adjust./oper.checkout
Chargevoltage
confirmation
Heatingunit
confirmation
Levelsensor
confirmation
Excitation
adjustment
Manual
Shut
down

Phasemargintest


Auto-phasegain
adjustment



Status：ＸＸＸＸＸ
Decre-
ment
Back
０９８７６５４３２１
Auto-phasegainadjustment
Incre-
ment
 Auto-phasegainvalue[４０]（２〜６２）
Automatic
acquisition

← →
Status：ＸＸＸＸＸ
Solenoidvalve/
pumptest
Adjustment/
operationalcheckout
LanguagechangeUnitinformation
Systemreset
System
environmentsetup
Download
Next
menu
Back
Maintenancemenu
Manual
Shut
down



Status：ＸＸＸＸＸ
