2-4
Conditions set by the ink type*1
Nozzle
size
Ink type
Excitation
frequency
(kHz)
Excitation
curve
Operating
temperature
upper limit
(℃)
Operating
temperature
lower limit
(℃)
JP-K67 68.9 01 45 0
JP-K69 68.9 02 45 0
JP-K26 68.9 05 35 0
JP-K27 68.9 06 45 0
JP-R27 68.9 07 35 0
JP-G27 68.9 08 35 0
JP-B27 68.9 09 35 0
JP-K28 68.9 10 35 0
JP-K31A 68.9 11 35 0
JP-K33 74.0 13 35 0
JP-K60 68.9 14 35 0
JP-K61 68.9 15 35 0
JP-K62 68.9 16 35 0
JP-F63 68.9 17 35 0
JP-T64 68.9 18 35 0
JP-K65 68.9 19 35 0
JP-R65 68.9 20 35 0
JP-K68 68.9 21 35 0
JP-K70 68.9 22 35 0
JP-T71 68.9 23 35 0
65μｍ
JP-K72 68.9 24 40 0
Note: *1 When the ink type is set, an initial value is automatically set.
With respect to full details about the excitation curve, refer to the
attached figure 7.3.
*2 The ink type was set to JP-K33 when the printer was shipped from
the
factory: Be sure to change the setting on the ink type to be used.
To Next Page
