6 Optional functions
231
6
SMGB0077 rev.0 - 01/2013
Element Optional function
Individual
setting
Settings Condition setting Description
H5
Central control available after
forced stoppage
O
00 Not available
This function allows for central control
after the forced stoppage of the unit.
01 Available
PC-ARF: Not available – –
Not available
Use at 00 conditions
–
J1
Temperature indication
X
00 Not available PC-ARF only
01 Available PC-ARF only
J2
Not available
– – Not Used PC-ARF only
J3
Run indicator color
X
00 Green PC-ARF only
01 Red PC-ARF only
J4
Not available
– –
Not available
Use at 00 conditions
PC-ARF only
J5
Not available
X –
Not available
Use at 00 conditions
PC-ARF only
J6
Error sound
X
00 Once PC-ARF only
01 Sequence PC-ARF only
J7
Not available
– – Not available PC-ARF only
J8
Eco-operation
(6)
X
00
Not activated
function
PC-ARF only
01 Activated function PC-ARF only
J9
Not available
– –
Not available
Use at 00 conditions
PC-ARF only
JA
Not available
– –
Not available
Use at 00 conditions
PC-ARF only
Jb
Not available
– –
Not available
Use at 00 conditions
PC-ARF only
1-1
Not available
X –
Not available
Use at 00 conditions
PC-ARF only
1-2
Not available
X –
Not available
Use at 00 conditions
PC-ARF only
1-3
Not available
X –
Not available
Use at 00 conditions
PC-ARF only
1-4
Not available
– –
Not available
Use at 00 conditions
PC-ARF only
1-5
Human sensor detection
level
–
00 Standard PC-ARF only
01 High PC-ARF only
02 Low PC-ARF only
O: allows for individual setting.
X: the setting is made for all outdoor units.
–: not used.
(1)
Setting 02 is not available on all indoor units.
(2)
On RPI units: 00 Increases speed 1 (standard), 01 Increases speed 2 (high static pressure), 02 Standard speed (low
static pressure).
(3)
00 standard (7-step operation); 01 draft prevention (cannot be set below two steps); 02 High ceilings (cannot be set
above two steps).
