6 Optional functions
230
SMGB0077 rev.0 - 01/2013
Element Optional function
Individual
setting
Settings Condition setting Description
FC
Cooling lower limit for setting
temperature
X
00 Standard
This function is used to deîš¿ne a lower
temperature setting limit for FAN/
COOL/DRY modes.
01 Lower limit +1 °C
02 Lower limit +2 °C
03-08
Lower limit +(03-
08) °C
09 Lower limit +9 °C
10 Lower limit +10 °C
Fd
Heating upper limit for setting
temperature
X
00 Standard
This function is used to deîš¿ne an
upper temperature setting limit for
HEAT mode. PC-ARF: up to -12 °C
01 Lower limit -1 °C
02 Lower limit -2 °C
03-08
Lower limit -(03-
08) °C
09 Lower limit -9 °C
10 Lower limit -10 °C
FE
Not available –
00
Not available
Use at 00 conditions
–01
02
FF
PC-ART: Lock function for timer X
00
Not activated
function
This function is used to lock timer
activation.
01
Activated function
(factory setting)
PC-ARF: Not available – –
Not available
Use at 00 conditions
–
H1
Maintenance alarms O
00 Display
This function is used to display or hide
maintenance alarms.
01 Hide
PC-ARF: Not available – –
Not available
Use at 00 conditions
–
H2
PC-ART: Automatic control
indication
PC-ARF: Indication of hot start
O
00 Display
This function is used to display or hide
the automatic control indication.
01 Hide
H3
PC-ART: Operating mode
change restriction
O
00
Operating mode
change disabled
(factory setting)
This function is used to conîš¿gure
restrictions to the HEAT mode.
01
Operating mode set
by the central control
+ FAN mode
02
Unlimited operating
mode
–
PC-ARF: Not available – –
Not available
Use at 00 conditions
–
H4
PC-ART: Operating modes for
the ventilation unit with energy
/ heat recovery
O
00 Air conditioning only
This function is only available for the
ventilation unit with energy / heat
recovery.
01 Ventilation only
02
Air conditioning +
ventilation
PC-ARF: Not available – –
Not available
Use at 00 conditions
–
