Lift up the air lter, detach the catches from the indoor
unit and remove the air lter downward.
After the right arm shaft is pushed inward and the
shafts are removed from the front panel, pull the at
panel frontward while the right arm shaft is slightly
pushed inward.
Flat panel
Push the shaft
toward arrow di-
rection.
Remove this part
from the hole.
Attaching at panel for RPK-(2.0-4.0)FSN3M
Insert completely the left and right arm shafts of at panel into
the holes along the guide at the front panel. After the at panel is
attached completely, insert the catches for air lter to x.
Hole
Guide at
front panel
Front panel
Flat panel
C A U T I O N
When removing front panel, do not apply an excessive force by hitting, etc. It may break the unit body.
To Next Page
