Anti-bacteria lter
For RCI-FSN3 indoor units: F-160L-K
The dimensions of the long-lasting anti-bacteria lter are shown in the following gure.
(Large)
Air
To t the lter, insert the tab on the suction grille into the large hole in the lter, as shown in the gure below.
Model a (mm)
RCI-(1.0-2.5)FSN3 248
RCI-(3.0-6.0)FSN3 298
15
Air Inlet Grille
Air Panel
Antibacterical
Long Life Air Filter
840
Indoor Unit
*Put the square holes into the
extruded parts of air inlet grille.
Extruded Part*
• Specications
Part RCI-(1.0-6.0)
Dust collection efciency (%) 50 (gravimetric method)
Air ow rate (m
3
/min) 35.0
Initial pressure loss Pa 28.0
Final pressure loss Pa 62.0
Filter/Frame colour White/Brown
Working life 4 years (with maintenance every 1250 hours)
Cleaning Available
(*)
Weight (kg) 0.6
Performance Avoids the multiplication of bacteria and mold
Filter material
Antibacterial ber
Modied acrylic bre 1 (containing inorganic anti-bacterial substance)
Modied acrylic bre 2 (containing organic anti-bacterial substance)
Reinforce net PP
(*)
This is the standard working life of the lter and its duration may vary depending on the conditions of use. Clean the lter
with water or neutral detergent.
