117 IFP-300 / IFP-300ECS Manual P/N LS10145-001SK-E:B 12/18/2017
9.5.2 Point Programming For 6815 Module
To program for points on an 6815 module, follow these steps:
1. Enter the installer code. The panel will automatically go to the main menu.
2. Select 7 for Panel Programming.
SWITCH
(cont.)
ZONE AUX1 Latching Use these switch types if you want to monitor special zone-level
conditions (such as dry contact from a remote power supply).
Non Latching
ZONE AUX2 Latching
Non Latching
SYSTEM AUX1 Latching Use these switch types if you want to monitor special system-wide
conditions (such as dry contact from a remote power supply).
Non Latching
SYSTEM AUX2 Latching
Non Latching
DETECTOR Used to monitor conventional 4-wire detectors, a contact closure will
generate a detector alarm event.
FIRE TAMPER Latching Performs identically to a supervisory switch, but will be indicated as
a tamper switch on the LCD annunciator.
Non Latching
MANUAL
RELEASE
Manual release switch
INTERLOCK Interlock release switch input.
STATUS POINT
ECS INPUT Latching User also has ECS Event Number 1-8 option for ECS INPUT.
Only available when an ECS-VCM is installed in the system.
Non Latching
ECS TAMPER Latching
Non Latching
ECS SUPER-
VISORY
Latching
Non Latching
CO DETECT
SWITCH
CO Detector Switch
CO
SUPERVISORY
DETECT SWITCH
Latching CO Supervisory Detector Switch
Non Latching
NOTIF
OUTPUT PT Select Group Output point, a general use notification type. Use for driving
standard notification appliances.
AUX CONST Use constant power for applications that require a constant auxiliary
power source. Power is always present at constant circuits.
AUX RESET Use for auxiliary power, resettable applications. See Section
“Auxiliary Power Installation” on page 52 for a description of how
this option operates.
AUX DOOR Use for auxiliary power, door holder applications. For example, if
you were using an auxiliary power supply for door holders, you
would use this option. See Section “Door Holder Power” on page 52
for a description of how this option operates.
RELAY
OUTPUT PT Select Group Output point, a general use relay type. Use for applications requiring
a relay, such as fan shutdown, elevator recall, and so on.
AUX RESET Use for auxiliary power, resettable applications. See Section
“Resettable Power” on page 52 for a description of how this option
operates.
AUX DOOR Use for auxiliary power, door holder applications. For example, if
you were using an auxiliary power supply for door holders, you
would use this option. See Section “Door Holder Power” on page 52
for a description of how this option operates.
SLC LED
LED NUMBER 01-80 For use with SD devices only. 80 sub addresses on LED.
LED FUNCTION Unused
NOTIF Notification can have group number.
Type Selection Function Latching Option Comments
Table 9.4 Programming Options for 5815XL Modules
To Next Page
