  the YĆtensioner housing screw.

Torx-15

Loosen

 Slide the YĆtensioner housing out from

the YĆtensioner bracket.

Y-tensioner

bracket

Y-tensioner

housing

 Release the main idler from the

cartridgeĆcarriage belt.

 Lift the YĆtensioner housing clear of the

plotter.

6Ć47 Removal and ReplacementC3187Ć90000
