2Ć2 Site Planning and Requirements
C3187Ć90000
Power Requirements
HP C3180A and C3181A DesignJet 200 and HP C3187A and C3188A DesignJet 220 plotters
have selfĆadjusting power supplies and do not require a voltage selector or switch settings
prior to use. The table below lists the power requirements for the plotters.
Power Requirements
Source Voltage Requirements:
Frequency:
Voltage Max current (rms)
100 V ac 1.4 A
120 V ac 1.2 A
220 V ac 650 mA
240 V ac 600 mA
47-53 Hz and 57-63 Hz
Consumption: 140 watts maximum
WARNING
# ! ! " "
! ! %
!$ $ !
$ !
The power cord supplied with the plotter should meet the plug requirements for the
geographical area. However, different power cords (international options) are available.
(Cable part numbers ' chapter 10.)
Choosing an Interface Cable
(Instructions ' User's Guide, chapter 1, w Choosing an interface cable.)
&& A short cable (less than 15 meters or 50 feet) is recommended
for the RSĆ232ĆC interface. A longer cable is permissible, provided the load capacitance does
not exceed 2500 picofarads.
& Use a short cable (less than 2 meters or 6.6 feet)
for the parallel interface.
(Interface descriptions ' Service Manual, chapter 5, w Input/Output Interfaces.)
(Pin specifications ' User's Guide, chapter 6, w Interface specifications.)
(Cable part numbers ' Service Manual, chapter 10.)
