2Ć3 Site Planning and RequirementsC3187Ć90000
Choosing a Suitable Plotter Environment
(Instructions ' User's Guide, chapter 1, w Positioning the plotter.)
Environmental Specifications
Hardware: Environmental Class B2
Operating environment:
Plotter
With cartridges and media:
Optimal print quality and media
handling:
Temperature Relative Humidity
0 to 55_C (32 to 131_F) 20-80%
10 to 40_C (50 to 104_F) 20-80%
15 to 30_C (59 to 86_F) 20-80%
Storage environment:
Plotter/media
Cartridges
Temperature Relative Humidity
–40 to +70_C
(–40 to +158_F) 5-95%
–40 to +60_C
(–40 to +140_F)
Acoustics:*
Operating
Idle
Sound Pressure Sound Power
54 dB (Acoustic) 6.5 bels (A)
< 20 dB (A) < 3.6 bels (A)
These specifications are typical sound pressures at a oneĆmeter bystander position. Idle specification
assumes fan is off.
Plotter Dimensions and Weight
Plotter Model: C3180A/C3187A C3181A/C3188A
Length
Depth
Height (window closed)
Height (window open)
Weight
1076 mm (42.36 in) 1375 mm (54.13 in)
380 mm (14.96 in) 380 mm (14.96 in)
355 mm (13.97 in) 355 mm (13.97 in)
505 mm (19.88 in) 505 mm (19.88 in)
39.1 kg (86.2 lbs) 46.7 kg (103.0 lbs)
