294
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
vpn-instance vpn-instance-name: Specifies an MPLS L3VPN instance by its name, a case-sensitive string
of 1 to 31 characters. If no VPN instance is specified, the command displays dampened BGP IPv4 unicast
routes for the public network.
Usage guidelines
The command with the unicast keyword has the same effect as that without the unicast keyword.
Examples
# Display dampened BGP IPv4 unicast routes.
<Sysname> display bgp routing-table dampened ipv4
Total number of routes: 1
BGP local router ID is 192.168.1.135
Status codes: * - valid, > - best, d - dampened, h - history,
s - suppressed, S - stale, i - internal, e - external
Origin: i - IGP, e - EGP, ? - incomplete
Network From Reuse Path/Ogn
de 20.1.1.0/24 10.1.1.2 00:56:27 100i
Table 78 Command output
Field Description
Status codes
Status codes:
• * – valid—Valid route.
• > – best—Best route.
• d – dampened—Dampened route.
• h – history—History route.
• s – suppressed—Suppressed route.
• S – stale—Stale route.
• i – internal—Internal route.
• e – external—External route.
Origin
Origin of the route:
• i – IGP—Originated in the AS. The origin of summary routes and routes
advertised with the network command is IGP.
• e – EGP—Learned through EGP.
• ?– incomplete—Unknown origin. The origin of routes redistributed from IGP
protocols is INCOMPLETE.
Network Destination network address.
