Field Descri
p
tion
Multi-VPN-Instance
Indicates whether the OSPFv3 process supports PE or
multiple VPN instances:
• Multi-VPN-Instance: Disabled—The process does
not support multiple VPN instances.
• Multi-VPN-Instance: Enabled—The process supports
multiple VPN instances.
• PE Router, Multi-VPN-Instance: Enabled—The local
device is a PE.
DN-bit check
Indicates whether the check is enabled for the DN bit in
OSPFv3 LSAs of the OSPFv3 process.
DN-bit set
Indicates whether the DN bit is set for OSPFv3 LSAs in
the OSPFv3 process.
Condition
Time when the router acts as a stub router:
• Always.
• On startup while BGP is converging for xxx seconds,
where xxx is specified by the user.
• On startup for xxx seconds, where xxx is specified
by the user.
State
State of the stub router:
• Active.
• Inactive.
SPF-schedule-interval Interval for SPF calculations.
Transmit pacing
LSU advertisement rate:
• Interval—Specifies the interval for sending LSUs.
• Count—Specifies the maximum number of LSUs sent
at each interval.
Default ASE parameters
Default parameters of redistributed routes. Tag
represents the route tag of the redistributed routes.
Route preference Internal route preference.
ASE route preference AS-external route preference.
LSA originated count Number of originated LSAs.
LSA received count Number of received LSAs.
Area count Total number of areas.
Stub area Count Number of stub areas.
NSSA area Count Number of NSSA areas.
ExChange/Loading neighbors Neighbors in ExChange/Loading state.
