7
Specifkations and Measurement Uncertainties
Dynamic Range
The specifications described in the table below apply to transmission measurements using 10 Hz
IF BW and full 2-port correction. Dynamic range is limited by the maximum test port power
and the receiver’s noise floor.
‘able 7-1. HP8753E Dynamic Range
Frequency Range
30 kHz to 300 kHz
3OOkHzt~1.3GHz
1.3GHzto3GHz
3GHzto6GHz
* Typical
*WOdB,30kHzto5OkHz
t 100 dB, 300 kHz to 16 MHz, due to fixed spun
1 105 dB, Option 075
Dynamic Range
100 dB* **
110 dBt $
110 dB$
105 dB
Speoifisations and Measurement Unwrtainties 7-l
