Troubleshooting LAN Problems

If the symptom is that there is no communication over the network, refer to <Undefined

Cross-Reference>.

Table 3-12 LAN Troubleshooting Procedure

Cause Action

Bad cable or

connection.

Check cable connections at all connection points.

Replace the 10 base-T cable.

Verify LAN port configuration in the system.

Call the Response Center.

Bad LAN

component

Run appropriate LAN diagnostic.

Replace indicated component.

Verify LAN port configuration in the system.

Call the Response Center.

Unknown problem Call the Response Center.
