Chapter 11 11-81

SCSI Peripherals and I/O Information

• 7200 rpm spindle speed

• Average latency = 4.17 ms

• MTBF = 1,000,000 hours

• No preventative maintenance or adjustments required

• Low power consumption

Table 11-33 4 Gb SE Disks

NOTE The Product Revision Level String is subject to change due to newer firmware

revisions.

Figure 11-45 A3660A Jupering (ST34371N / ST345555572N)

Vendor ID

String

Product

ID String

Product Revision

Level String

SEAGATE ST34371

HPM3

SEAGATE ST34572

HP03

QUANTU

XP34361

HP15
