4-18 Chapter 4

D200/D210/D310 Front Panel LCD Codes

Major Code Category A: Boot Device Initialization

Errors

Table 4-11 Boot Device Initialization Errors

Ostat Code Name Meaning

WARN A008 NO_BOOT_SELECTION No bootable device found

WARN A00F REYRIEVE_PATH_FAILED Failed retrieving boot path.

WARN A50F INIT_PRI_PATH_FAILED Call to init_boot_device

WARN A70F INIT_OTHR_PATH_FAILED Call to init_boot_device

FLT A088 NO_BOOT_NOCONS No console, unable to boot.

WARN A0BD DEVICE_NOT_READY IODC returned -8.
