HP 9000 Series - Table 7-1 Major Code Category Definitions

To Next Page

To Previous Page

7-2 Chapter 7

Dx20/Dx30 Front Panel LCD Codes

Table 7-1Major Code Category Definitions

Code Description

0 Reserved

1 Interrupts, Selftests, Diagnostics, and Boot codes

2 Cache (selftests and diagnostics)

3 Processor Dependent Hardware (PDH)

4 Late Selftests

5Bus Transactions

6 Reserved

7 Memory Subsystem Faults and PDCE_HPMC Memory Faults

8 I/O Device Faults

9 Console Initialization Errors

A Boot Device Initialization Errors

B Operating System Panic (OS)

C System Initialization (Processor, Memory, Monarch Extended Selftest, console, Boot

device and IPL for primary path, Boot device and IPL for all other paths, TOC, LPMC,

HPMC, Slave CPU, Bus) Codes

D Shutdown Codes (OS)

EWarning Codes (OS)

FRun Codes (OS)
