HP 9000 Series - Preventative Maintenance

To Next Page

To Previous Page

Chapter 11 11-79

SCSI Peripherals and I/O Information

Preventative Maintenance

There is no preventative maintenance required for this product.

Troubleshooting

This product is considered a single FRU, the drive busy LED is only used to show activity.

Diagnostics

SCSIDSK2

Exchange Part Number

A3304-69001 (ST32550N / XP32150L)

A3304-69003 (ST32171N / ST32272N / XP32181S)

19-20 Spindle Sync.

Connector Pin-set Function Configuration
