Chapter 11 11-73
SCSI Peripherals and I/O Information
• Synchronous spindle capability
• Data buffer size = 512 Kbytes
• Formatted data capacity limited to = 2132.62 Mbytes for compatability
• Programable sector reallocation scheme
• Flawed sector reaalocation at format time
• Reallocation of defects on command (post format)
• Embedded Grey Code track address to eliminate seek errors
• Command Queuing - 64 commands
• 7200 rpm spindle speed
• Average latency = 4.17 ms
• MTFB = 800,000 hours
• No preventative maintenance or adjustments required
• Low power consumption
• Vendor Indentification String = SEAGATE
• Product Indentification String = ST3225N
• Product Revision Level String = HP06 Multiuser
NOTE The Product Revision Level String is subject to change due to newer firmware
revisions.
Jumpering
Figure 11-39 A3304A Jumpering
Table 11-27 J1 Jumper Function Description
Source Pins
Terminator Power From Drive 1 &2
Terminator Power to SCSI Bus Pin 26 1 &3 (Default setting)
Terminator Power From SCSI Bus Pin 26 2 &4
Terminator Power to SCSI Bus and Drive 1 &3, 2 &4
SCSI Terminator Enable 5 &6
