&KDSWHU  

,QWURGXFWLRQ

Figure 1-4 R Class Rear Panel Connectors, Controls, and Indicators

,WHP 'HVFULSWLRQ

1 I/O (HSC and EISA) card slots

2 Transfer Of Control button

3 Link beat LED

4Term power LED

5 Serial 1/Console connector

6 Serial 2/UPS connector

7 Parallel connector

8 SCSI (Single-ended) connector

9 PS/2 keyboard connector

10 PS/2 mouse connector

11 LAN 10 Base-T connector

12 Power cord connector

13 Regulatory information
