Chapter 7 7-13
Dx20/Dx30 Front Panel LCD Codes
Major Code Category 7: Memory Subsystem Faults
and PDCE_HPMCX Memory Faults
Table 7-8 Memory Subsystem Codes
Ostat Code Description
FLT 7000 HPMC in the memory system
FLT 70FF Unknown HPMC
FLT 7301 SIMM 0 bytes are not equal
FLT 7302 SIMM 1 bytes are not equal
FLT 7303 SIMM 0 data and SIMM 1 data have a mismatch error
FLT 7304 Unknown sizing compare fault
FLT 7307 ECC test failed on memory bank
FLT 7403 Address did not map to bank
FLT 7406 SLC to memory access fault
FLT 7407 SLC tag parity fault
FLT 7500 No RAM found
FLT 7604 No bits set in memory test status
WARN 7702 Memory not tested, initialized only
PDCE_HPMC Memory Fault Codes
FLT 7C00 HPMC on memory read
FLT 7C01 Expected HPMC did not occur
FLT 7C02 DR0 memory read check in unexpected state after reading good data
FLT 7C03 Unexpected data read back
FLT 7C04 DR0 memory read check in unexpected state after reading bad data
FLT 7C05 MIOC status in unexpected state
FLT 7C06 DR memory ERR0 in unexpected state
FLT 7C07 DR memory ERR1 in unexpected state
FLT 7C08 MDERRADD in unexpected state
FLT 7D08 Memory multiple bit fault
