HP 9000 Series Service Manual

Chapter 9 9-3
Replaceable Parts
Table 9-2 Non-Exchange Assemblies
A3349-60001 A3349-69001 1Gb SE-SCSI disk drive 6
A3304-60001 A3304-69001 2Gb SE-SCSI disk drive 6
A2944-60001 A2944-69001 QIC tape drive 7
A4081-66009 A4081-69009 (A4077A) 2D HSC graphics PCA
HP Part Number Description
Locator
Number
A3262-81003 D2xx Hot Swap assembly
8
1
A3268-81003 D3xx Hot Swap assembly 8
0950-2726 350W Power Supply 9
0950-3245 450W Power Supply 9
0950-3123 650W Power Supply 9
A3262-60001 Chassis assembly (D Class) 10
A5176-04001 Chassis assembly (R Class)
A3262-60021 Front Bezel assembly (D Class) 11
A5176-04006 Front Bezel Assembly (R Class)
A5176-40001 Front Bezel, outer (R Class) 20
A5176-40002 Front Bezel, inner (R Class) 21
5176-84001 Nameplate (R Class)
A4450-66501 Visualize-EG EISA PCA
A4200-66540 512Kb Cache PCA
A4452-66501 2Mb EG Display Memory PCA
A2636-66023 (A2999A) 2D HSC graphics PCA
A3262-63007 S/E SCSI internal cable
3160-0422 Fan cover
A3262-00041 Fan bracket
A3262-60031 Fan assembly, 2 each
12
2
A3262-60023 Media assembly (D Class) 13
A5176-10004 Media assembly (R Class)
New HP Part
Number
Exchange HP
Part Number
Description
Locator
Number
